Robustel LG5120 Building Automation Gateway Ireland

Robustel LG5120 Building Automation Gateway for Ireland

The Robustel LG5120 is an industrial-grade edge computing gateway engineered specifically for building automation and facility management. As the official Irish distributor for Robustel, TITAN IoT supplies the LG5120 to building services engineers, integrators and facilities teams across Ireland who need a single platform that consolidates the protocols buildings actually use — KNX, BACnet, Modbus RTU, M-Bus, OPC-UA and LoRaWAN — with local processing, automation logic and visual dashboards at the edge.

IRISH APPLICATIONS

The LG5120 fits Irish projects where multi-protocol building data needs to be consolidated, processed locally and either visualised on-site or forwarded to a BMS or cloud platform:

• Commercial buildings and offices — consolidating HVAC, lighting, access control and sub-metering into a single integration layer
• Hospitals, schools and campuses — environmental monitoring, pharmacy cold-store alarms, classroom IAQ/CO&sub2; tracking
• Energy management and carbon reporting — aggregating M-Bus heat/water/gas meters with LoRaWAN energy sensors for SEAI and carbon-neutrality reporting
• Retail, hospitality and mixed-use developments — sub-metering, occupancy and HVAC integration
• Projects where cellular backhaul is needed on Vodafone, Three and Eir

BUILDING PROTOCOL INTEGRATION

A dedicated KNX TP port and KNXnetIP over Ethernet connect directly to lighting, HVAC and room management without a separate protocol converter. Two isolated RS-485 ports handle Modbus RTU and BACnet MS/TP field devices. M-Bus manages heat, water and energy meter networks. A dedicated P1/DSMR port (up to 115,200 bps) connects to smart meters in markets like the Netherlands and Belgium. Two software-configurable analog inputs (0–24 V or 4–20 mA) accommodate sensors that don’t use a digital bus. An onboard Semtech SX1302 LoRaWAN chipset covers wireless sensors across 8 channels on EU868.

E2C FACILITY SUITE — EDGE AUTOMATION

The E2C Facility Suite is what makes the LG5120 more than a gateway: unified data acquisition across KNX, BACnet, Modbus and OPC-UA; Node-RED orchestration with automated scene management for trigger-based control; BACnet IP and OPC-UA data forwarding to external BMS or SCADA systems; and a drag-and-drop HMI/SCADA dashboard builder with real-time multi-channel alarms.

FREE RCMS CLOUD MANAGEMENT

The LG5120 is RCMS ready, giving Irish customers free centralised cloud-based monitoring, remote diagnostics, configuration and firmware management. Particularly useful where building gateways are spread across multiple sites or campuses.

ROBUSTOS PRO — FULL DEBIAN LINUX

The LG5120 runs RobustOS Pro, a full Debian Linux operating system with multi-language SDK (C, C++, Python, Java, Node.js). 7 GB of RAM and 60 GB of flash are available to the SDK, with a 2.3 TOPS NPU for edge AI workloads.

RECOMMENDED ANTENNAS

For better performance and easier project specification, pair the LG5120 with:

• Poynting PUCK-2 — cellular antenna for panel or cabinet installations
• Poynting XPOL-2 — cellular antenna for challenging signal environments
• A dedicated 868 MHz LoRa antenna for the EU868 LoRa interface

KEY FEATURES

• Industrial building automation edge gateway for KNX, BACnet, Modbus, M-Bus, LoRaWAN and OPC-UA
• Works across Vodafone, Three and Eir
• Dedicated KNX TP + KNXnetIP over Ethernet
• BACnet MS/TP, Modbus RTU, M-Bus, OPC-UA onboard
• P1/DSMR port for smart-meter integration
• 8-channel LoRaWAN EU868 (also AU915 / AS923 variants)
• E2C Facility Suite with Node-RED, scenarios, HMI/SCADA dashboard builder
• 2.3 TOPS NPU for edge AI and analytics
• Quad-core ARM Cortex-A53 @ 1.6 GHz, 8 GB DDR4, 64 GB eMMC
• 2 x Gigabit Ethernet ports, Wi-Fi 6 (802.11ax dual-band)
• RobustOS Pro Debian Linux with multi-language SDK
• RCMS cloud management enabled — free for life
• Operating temperature -40 to +70 °C, IP30 metal housing
• Mounting options — desktop, wall mount and 35 mm DIN rail

KEY SPECIFICATIONS

• CPU / Memory: Quad-core ARM Cortex-A53 @ 1.6 GHz, NPU 2.3 TOPS, 8 GB DDR4, 64 GB eMMC
• Operating system: RobustOS Pro (Debian Linux)
• Cellular: 4G LTE / 3G / 2G; 2 x Mini SIM (2FF), dual-SIM failover
• Irish network compatibility: Suitable for deployments using Vodafone, Three and Eir
• LoRa: EU868 (also AU915 / AS923); 8 channels simultaneously; SX1302 chipset
• Ethernet: 2 x RJ45 10/100/1000 Mbps, configurable as 1 x WAN + 1 x LAN or 2 x LAN
• Wi-Fi: 802.11 a/b/g/n/ac/ax (Wi-Fi 6), dual-band 2.4 / 5 GHz
• Building protocols: KNX TP, KNXnetIP, BACnet MS/TP, BACnet IP, Modbus RTU, M-Bus, P1/DSMR, OPC-UA
• Serial: 1 x M-Bus, 1 x KNX, 1 x P1, 2 x isolated RS-485, 1 x RS-232
• I/O: 2 x DI, 2 x DO (wet contact), 2 x AI (0–24 V or 4–20 mA)
• USB: 1 x USB 3.0 host (Type A)
• GNSS: Integrated
• Power input: 9–60 V DC (12/24/48 V DC nominal), reverse polarity and surge protection
• Power consumption: Idle 5 W, max 20 W @ 12 V
• Operating temperature: -40 to +70 °C
• Ingress protection: IP30
• Housing: Metal, 560 g
• Dimensions: 49 x 105 x 128 mm
• Mounting: Desktop, wall mount, 35 mm DIN rail

Note: The LG5120 is currently in pre-production. Specifications are subject to minor change until release. Contact TITAN IoT for availability and lead times.

Download the Robustel LG5120 Datasheet

FREQUENTLY ASKED QUESTIONS

Does the LG5120 work on Irish networks?
Yes — the EU variant is supplied for use on Vodafone, Three and Eir, with EU868 LoRa and full European 4G LTE band support.

What building protocols does the LG5120 support out of the box?
KNX TP and KNXnetIP, BACnet MS/TP and BACnet IP, Modbus RTU and Modbus TCP, M-Bus, P1/DSMR, and OPC-UA — all integrated via the E2C Facility Suite without requiring external converters.

What mounting options does the LG5120 support?
Desktop, wall mount and 35 mm DIN rail.

Can I get technical support in Ireland?
Yes — TITAN IoT in Galway provides local pre-sales, technical and post-sales support. Call +353 91 757500 or request a quote through the website.
