L[X]A[X]M4-7-42[-X] – 4×4 MIMO 5G/4G cellular antenna for IoT applications from Panorama Antennas

The L[X]A[X]M4-7-42[-X] is a 4×4 MIMO 5G/4G cellular antenna from Panorama Antennas with an omnidirectional radiation pattern, a robust IP69K housing and designed for IoT applications. It is also optionally available with up to 4×4 MIMO Wi-Fi 6e and GPS/GNSS.

  • 4×4 MIMO 5G/4G cellular antenna
  • Supports 686-960/1427-4200 MHz frequencies
  • Features a robust IP69K and IK10 compliant housing
  • Particularly suitable for IoT (Internet of Things) applications
  • Variants with up to 4×4 MIMO Wi-Fi 6e and GPS are also available
SKU: LPAM4-7-42 Categories: ,

L[X]A[X]M4-7-42[-X] – 4×4 MIMO 5G/4G cellular antenna from Panorama Antennas for IoT applications with optional up to 4×4 MIMO Wi-Fi 6e and GPS/GNSS

The L[X]A[X]M4-7-42[-X] is an omnidirectional 4×4 MIMO 5G/4G cellular antenna for IoT (Internet of Things) applications, which is equipped with a robust housing that complies with both IP69K and IK10 protection class. It supports the 698-960 MHz and 1427-4200 MHz cellular frequencies, but is also available with up to 4×4 MIMO Wi-Fi 6e (2.4-7.2 GHz) and GPS/GNSS (1559-1612 MHz). This 4G LTE/5G NR cellular antenna is usually mounted on panels or plates with a maximum thickness of up to 4 mm. Brackets for mast or wall mounting are available as optional accessories. The L[X]A[X]M4-7-42[-X] also has several CS30 cables (UN ECE R118 compliant) with either SMA (M) or RP-SMA connectors to facilitate connection to compatible devices (e.g. routers, gateways, etc.).

Characteristics

  • 4×4 MIMO 5G/4G cellular antenna
  • Covers the 698-960/1427-4200 MHz frequencies
  • Also available optionally with L1 or L1/L5 GPS/GNSS
  • Variants with up to 4×4 MIMO Wi-Fi 6e (2.4-7.2 GHz) are available
  • Has an omnidirectional radiation pattern and an antenna gain of up to 8.6 dBi
  • Offers up to 9x UN ECE R118 compliant CS30 cables with SMA (M) and RP-SMA connectors
  • Is equipped with an IP69K and IK10 compliant Lexan EXL 9330 housing
  • Suitable for mounting on panels, boards or similar
  • Brackets for wall and mast mounting are optionally available
  • Developed for IoT (Internet of Things) applications
  • Has an operating temperature of -40 °C to 85 °C
  • Size (L x W x H): 11.8 x 17.5 x 5.7 cm



Orders numbers
LPAM4-7-42 4×4 MIMO 5G/4G cellular antenna
LPADM4-7-42 4×4 MIMO 5G/4G cellular antenna with 2×2 MIMO Wi-Fi (2.4-7.2 GHz)
LPAQM4-7-42 4×4 MIMO 5G/4G cellular antenna with 4×4 MIMO Wi-Fi (2.4-7.2 GHz)
LGAM4-7-42 4×4 MIMO 5G/4G cellular antenna with L1 GPS (1559-1612 MHz)
LGADM4-7-42 4×4 MIMO 5G/4G cellular antenna with 2×2 MIMO Wi-Fi (2.4-7.2 GHz) and L1 GPS (1559-1612 MHz)
LGAQM4-7-42 4×4 MIMO 5G/4G cellular antenna with 4×4 MIMO Wi-Fi (2.4-7.2 GHz) and L1 GPS (1559-1612 MHz)
LG5AM4-7-42 4×4 MIMO 5G/4G cellular antenna with L1/L5 GPS (1164-1189/1559-1612 MHz)
LG5ADM4-7-42 4×4 MIMO 5G/4G cellular antenna with 2×2 MIMO Wi-Fi (2.4-7.2 GHz) and L1/L5 GPS (1164-1189/1559-1612 MHz)
LG5AQM4-7-42 4×4 MIMO 5G/4G cellular antenna with 4×4 MIMO Wi-Fi (2.4-7.2 GHz) and L1/L5 GPS (1164-1189/1559-1612 MHz)
Brand

ANTENNA TYPE

Omnidirectional

MIMO

4×4 MiMo

MOUNTING

Spigot, Surface, Through-hole, Wall

TECHNOLOGIES

GPS/GNSS
