GPS[X]D4[X]-6-60[-X] – 4×4 MIMO 4G/5G LTE GPS/GNSS antenna with up to 6×6 MIMO WiFi 6e from Panorama Antennas

The GPS[X]D4[X]-6-60[-X] is a 4×4 MIMO 4G/5G LTE GPS/GNSS antenna from Panorama Antennas that can provide up to 6×6 MIMO WiFi6 and is equipped with a compact IP69K housing. It also has a connection for an additional rod antenna and has an operating temperature of -40 °C to 80 °C.

  • 4×4 MIMO 4G/5G LTE GPS/GNSS antenna
  • Offers up to 6×6 MIMO dual-band Wi-Fi (WiFi 6e)
  • Features an omnidirectional radiation pattern
  • Is equipped with a connection for an external rod antenna
  • Has a robust IP69K housing and is ideal for industrial and transport applications
SKU: GPS2D4[W]-6-60 Categories: ,

GPS[X]D4[X]-6-60[-X] – 4×4 MIMO 4G/5G LTE GPS/GNSS antenna from Panorama Antennas with up to 6×6 MIMO WiFi 6 for industrial or transportation applications

The GPS[X]D4[X]-6-60[-X] is a 4×4 MIMO 4G/5G LTE GPS/GNSS antenna that can provide up to 6×6 MIMO dual-band Wi-Fi and supports WiFi 6e. It also has a connector for an external rod antenna and is suitable for transportation and industrial applications. This GPS[X]D4[X]-6-60[-X] can have up to 4x active antennas for GPS/BeiDou/GLONASS/Galileo each with 26 dB gain LNA and advanced filtering for LTE band 13/14 operation. It offers an omnidirectional radiation pattern and only requires a 19mm hole for mounting to minimize damage and reduce installation time. This 4×4 MIMO 4G/5G LTE GPS/GNSS antenna features a compact rugged IP69K housing with a shark fin design and an operating temperature of -40 °C to 80 °C. It should be mounted on a metal plate when a rod antenna is used

Characteristics

  • 4×4 MIMO 4G/5G LTE GPS/GNSS antenna
  • Features up to 6×6 MIMO dual-band Wi-FI (WiFi 6e)
  • Is equipped with a connection for an external rod antenna (UHF, VHF)
  • Can provide up to 4x active antennas for GPS/GLONASS/BeiDou/Galileo each with 26 dB gain LNA and filtering for LTE Band 13-14 operation
  • 4G/5G elements have up to 5 dBi (617-960 MHz), 8 dBi (1427-4200 MHz) or 9 dBi (4900-6000 MHz) and Wi-Fi elements up to 7 dBi (2396-2485 MHz) or 11 dBi (4900-7200 MHz)
  • Covers 617-960/1427-6000 MHz (4G/5G), 2396-2485/4900-7200 MHz (Wi-Fi) and 1562-1612 (GPS/GNSS) frequencies
  • Has an omnidirectional radiation pattern and is UN ECE 118 certified
  • Offers multiple cables with FME (m), FME (f), SMA (m) and SMA (f) connectors
  • Features a compact IP69K housing with a shark fin-like design
  • Only requires a 19mm hole for mounting to reduce time and damage
  • If a rod antenna is used for communication, the antenna should be mounted on a metal plate
  • Suitable for transport or industrial applications
  • Operating temperature: -40 °C to 80 °C
  • Size (L x W x H): 14.2 x 25.3 x 8.2 cm
Order numbers
GPS2D4[W]-6-60-Q 4×4 MIMO 4G/5G LTE antenna with 2x GPS/GNSS and 4x WiFi elements
GPS2D4[W]-6-60-T 4×4 MIMO 4G/5G LTE antenna with 2x GPS/GNSS and 3x WiFi elements
GPS2D4[W]-6-60-D 4×4 MIMO 4G/5G LTE antenna with 2x GPS/GNSS and 2x WiFi elements
GPS2D4[W]-6-60 4×4 MIMO 4G/5G LTE antenna with 2x GPS/GNSS elements
GPSD4[W]-6-60-Q 4×4 MIMO 4G/5G LTE antenna with 1x GPS/GNSS and 4x WiFi elements
GPSD4[W]-6-60-T 4×4 MIMO 4G/5G LTE antenna with 1x GPS/GNSS and 3x WiFi elements
GPSD4[W]-6-60-D 4×4 MIMO 4G/5G LTE antenna with 1x GPS/GNSS and 2x WiFi elements
GPSD4[W]-6-60 4×4 MIMO 4G/5G LTE antenna with 1x GPS/GNSS element
FIND4[W]-6-60-Q 4×4 MIMO 4G/5G LTE antenna with 4x WiFi elements
FIND4[W]-6-60-T 4×4 MIMO 4G/5G LTE antenna with 3x WiFi elements
FIND4[W]-6-60-D 4×4 MIMO 4G/5G LTE antenna with 2x WiFi elements
FIND4[W]-6-60 4×4 MIMO 4G/5G LTE antenna
Brand

ANTENNA TYPE

Omnidirectional

MIMO

4×4 MiMo

MOUNTING

Spigot, Surface, Through-hole, Wall

TECHNOLOGIES

GPS/GNSS
