The Kerlink Wirnet iStation is Kerlink’s established outdoor LoRaWAN gateway: the mast- or roof-mounted base station for town, campus, utility and agricultural networks. Its antennas for LoRa, 4G and GPS are built in, and its connectors are waterproof, so installation needs no extra antenna work and the IP67 casing stays sealed.
It receives on 8 LoRa channels with -141 dBm sensitivity at SF12, backhauls over 4G with 3G/2G fallback or Ethernet, and is powered over Ethernet. Kerlink includes an embedded ChirpStack network server, zero-touch provisioning and access to its wiki; the optional Maintain programme adds the Wanesy Management Cockpit for remote health monitoring and updates.
An optional external LoRa antenna (3 or 6 dBi) and surge protection are available. Supplied and staged by TITAN in Galway.
Datasheet available on request.
